15Inch PCAP touch screen portable monitor with real mount

Short Description:

15 inch PCAP touch monitor delivers an industrial-grade solution that is cost-effective for OEMs and systems integrators requiring a reliable product for their customers. Designed with reliability from the start, CJTOUCH’s open frames deliver outstanding image clarity and light transmission with stable, drift-free operation for accurate touch responses. The F-Series product line is available in a wide range of sizes, touch technologies and brightness, offering the versatility needed for commercial kiosk applications from self-service and gaming to industrial automation and healthcare.


Product Detail

Product Tags

Specification:

General
Model COT150-CFF03
Series Water-proof and Open frame
LCD Type 15” Active matrix TFT-LCD
Video Input VGA ,DVI and HDMI
OSD controls Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply Type: External brick
Input (line) voltage: 100-240 VAC, 50-60 Hz
Output voltage/current: 12 volts at 4 amps max
Mount Interface 1)VESA 75mm and 100mm

2)Mount bracket, horizontal or vertical
LCD Specification
Active Area(mm) 304.128(H)×228.096(V)
Resolution 1024×768@60Hz
Dot Pitch(mm) 0.297×0.297
Nominal Input Voltage VDD +3.3V(Typ)
Viewing angle (v/h) 80°/80°
Contrast 500:1
Luminance(cd/m2) 250
Response Time(Rising) 8ms/12ms
Support Color 16.2M
Backlight MTBF(hr) 50000
Touchscreen Specification
Type Cjtouch Projected Capacitive touch screen
Multi touch 10points touch
Touch Life Cycle 10 millions
Touch Response time 8ms
Touch System Interface USB interface
Power consumption +5V@80mA
External AC Power Adapter
Output DC 12V /4A
Input 100-240 VAC, 50-60 Hz
MTBF 50000 hr at 25°C
Environment
Operating Temp. 0～50°C
Storage Temp. -20～60°C
Operating RH: 20%～80%
Storage RH: 10%～90%
https://www.cjtouch.com/15inch-pcap-touch-screen-portable-monitor-with-real-mount-product/
https://www.cjtouch.com/15inch-pcap-touch-screen-portable-monitor-with-real-mount-product/
https://www.cjtouch.com/15inch-pcap-touch-screen-portable-monitor-with-real-mount-product/

Components:

https://www.cjtouch.com/15inch-pcap-touch-screen-portable-monitor-with-real-mount-product/

USB Cable 180cm*1 Pcs,

VGA Cable 180cm*1 Pcs,

Power Cord with Switching Adapter *1 Pcs,

Bracket*2 Pcs.

https://www.cjtouch.com/32-inch-touch-screen-monitor-with-projected-capacitive-touch-screen-product/

Applications:

https://www.cjtouch.com/

♦ Information Kiosks
♦ Gaming Machine, Lottery , POS, ATM and Museum Library
♦ Government projects and 4S Shop
♦ Electronic catalogs
♦ Computer-based traning
♦ Eductioin and Hospital Healthcare
♦ Digital Signage Advertisement

♦ Industrial Control System
♦ AV Equip & Rental business
♦ Simulation Application
♦ 3D Visualisation /360 Deg Walkthrough
♦ Interactive touch table
♦ Large Corporates
