50 inch Capacitive nano pcap touch panel screen film touch foil with usb 10 points real multi points vandalproof waterproof outdoor
50 inch PCAP Touch Monitor specification :
|
1. General Specification
|
|
|
Touch Technology
|
PCAP project capacitive touch technology
|
|
Touch Panel Size
|
65inch 16:9
|
|
Input Medium
|
Finger, gloved hand, or passive stylus
|
|
Touch_Panel Structures
|
G+G
|
|
Total Thickness
|
5.3±0.15mm (Cover_Lens 4.0mm & Sensor 1.10mm)
|
|
Cover_Lens_Angle
|
4 x R11.5
|
|
Report Rate
|
≥100Hz
|
|
Positional Accuracy
|
±1.5mm
|
|
Surface Hardness
|
≧7H (Meets pencil hardness 7H per ASTM D 3363)
|
|
Cover_Lens
|
4mm tempered anti-vandal glass meet UL60950 stell ball drop
|
|
Haze(ASTM D 1003)
|
Clear surface≦3% Antiglare Surface≦4% Anti-Newton≦10%
|
|
Durability
|
Over 50 million touchs in one location
|
|
Touchscreen Operating Temperature
|
-20℃ ~ 70℃
|
|
Controller Operating Temperature
|
-20℃ ~ 70℃
|
|
Touchscreen Operating Humidity
|
20% ~ 90%RH (Non-condensing)
|
|
Controller Operating Humidity
|
20% ~ 90%RH (Non-condensing)
|
|
Storage Environmental
|
-30℃ ~ 80℃, RH<90% (Non-condensing)
|
|
2. Electrical Characteristics
|
|
|
Communication Interface(s)
|
USB (Standard) , RS-232, I2C (Options)
|
|
Supply Voltage
|
DC 5V
|
|
How to supply it
|
From COM / USB Port /Mainboard of PC
|
|
Number of Touches
|
Up to 16
|
|
Operating System
|
Windows XP, Windows 7, Windows 8, Windows 10, Linux, Android
|
|
Warranty
|
1 year
|
|
Agency Approvals
|
FCC,CE,ROHS
|
Applications:
♦ Information Kiosks
♦ Gaming Machine, Lottery , POS, ATM and Museum Library
♦ Government projects and 4S Shop
♦ Electronic catalogs
♦ Computer-based traning
♦ Eductioin and Hospital Healthcare
♦ Digital Signage Advertisement
♦ Industrial Control System
♦ AV Equip & Rental business
♦ Simulation Application
♦ 3D Visualisation /360 Deg Walkthrough
♦ Interactive touch table
♦ Large Corporates
