CJTouch industrial tablet computer 4G + 128G all-in-one wall-mounted computer mini computer for win 7 8 9 10 linux operating system
17 inch PCAP Touch Monitor specification :
|
Display
|
|
|
Screen
|
8" LCD
|
|
Resolution
|
1024*768
|
|
Brightness
|
350 cd/m2
|
|
Contrast Ratio
|
800:1
|
|
Performance
|
|
|
Chipset
|
Intel Celeron J1900/3865U/3855U/Core i3/i5/i7
|
|
Memory
|
2GB DDR3, up to 8GB; Intel3865U/3855U 2GB DDR4 up to 8GB; Core 2GB DDR4 up to 16GB
|
|
Storage
|
64GB SSD, up to 512GB Msata MLC SSD
|
|
Hardware Monitor
|
Monitors voltage, CPU, TEMP
|
|
Watchdog
|
0-255 sec by software
|
|
OS
|
Win10 and linux OS (J1900 also support win 7)
|
|
Power Supply
|
9-24V DC IN or 9-36V DC IN optional; 12V5A power adapter is standard
|
|
I/O
|
|
|
USB
|
J1900: 3*USB2.0+1*USB3.0; Core/3865U/3855U: 4*USB3.0
|
|
COM
|
4*RS232 (1 or 2*RS485/RS422 optional)
|
|
Ethernet
|
2*RJ45 GbE 1000M
|
|
Audio
|
1*Line out+1*Mic
|
|
Display
|
1*VGA+1*HDMI
|
|
Mini PCIe
|
1*MiniPCIe for WiFI/BT/3G/4G option
|
|
GPIO
|
1*4in/4out
|
|
Environmental
|
|
|
Anti-Vibration
|
5-19Hz/1.0mm amplitude;19-200Hz/1.0g, acceleration
|
|
Anti-shock
|
10g acceleration, 11ms duration
|
|
IP level
|
Front panel IP65(optional)
|
|
Reliability
|
MTBF≥5000h; MTTR≤0.5h
|
|
Working Temp.:
|
-10℃--50℃ with air flow
|
|
Strage Temp.:
|
-20℃ --60℃
|
|
Working Humidity
|
95% @40℃, non-condensing
|
|
Mechanical
|
|
|
Dimension
|
317(L)*246(W)*65.7(H)mm
|
|
Installation
|
VESA mounting: 100*100mm; Embedded mounting: 309*193mm
|
|
Material
|
Fanless High-strength and elegant Al-alloy panel
|
|
Weight
|
4.1kg/5.5kg(NET/Gross)
|
|
Color
|
Silver
|
|
Certificate
|
CE/FCC/RoHs certificate
|
|
Warranty
|
1 year warranty; extended warranty is available too.
|
Production process
Applications:
♦ Information Kiosks
♦ Gaming Machine, Lottery , POS, ATM and Museum Library
♦ Government projects and 4S Shop
♦ Electronic catalogs
♦ Computer-based traning
♦ Eductioin and Hospital Healthcare
♦ Digital Signage Advertisement
♦ Industrial Control System
♦ AV Equip & Rental business
♦ Simulation Application
♦ 3D Visualisation /360 Deg Walkthrough
♦ Interactive touch table
♦ Large Corporates
